hes 7500 Electric Strike-24VDC

HES 7501 ELECTRIC STRIKE  STAINLESS STEEL-24VDC

Grade 1

• Durability minimum - 500,000 cycles
  • U.L. Listed for 3 Hr. “A” label fire doors and burglary resistant
  • All stainless steel construction - tamper resistant
  • Forcing strength (in the opening direction) 1,500 lbs.
  • Field reversible - fail secure/fail safe
  • Door loading resistance - can operate under a pre-loaded condition (in the fail secure model only)
  • Non-handed
  • Horizontal adjustment
  • Plug-in connectors
  • Internally mounted solenoid
  • Continuous duty operation
  • 7500-105 goof plate trim adapter included
  • 24 VDC current draw = .25 AMPS
  • 3-year warranty
  • Standard Finish: 630 (Satin Stainless Steel)
  • Strike cutout: 4-7/8" x 1-1/4" x 1-1/2"
  • The 7501 is designed for all new or retrofit 4-7/8" ANSI jamb applications
  • Retrofits Folger Adams 712
