ARROW
Arrow QL-33R AR1-26D Asylum Lever set
- SKU:
- QL-33R
- UPC:
- Arrow M33SR- -AR1-26D -ASYLUM LE
- Availability:
- Arrow M33SR226D ASYLUM ,Leverset, Handlesets, Levers, knobs
- Weight:
- 2.00 LBS
- Shipping:
- Calculated at Checkout
Description
Arrow QL-33R AR1-26D Asylum Lever set
Asylum: Both levers always rigid. Either key will retract latch.
- Door Thickness: 1-3/8" To 1-3/4"
- Latchbolt: 1/2" Throw. Solid Brass Extruded. Latch Units Are Interchangeable
- Latch Front: Solid Brass And Bronze 2-1/4" X 1-1/8"
- Strike: Asa Strike 1-1/4" X 4-7/8"
- Cylinder: Solid Brass 6 Pin Cylinder, Pinned 5
- Certification: Grade 2 ANSI: A156.2 Series 4000. U.L. Listed, BHMA
- Installation: Cross Bore For Housing 2-1/8" Through Bore Latch Unit 7/8" Diameter. Mortise For Latch Front Is Required
- Packed 12 Per Case
- Backset: 2-3/4"
- Finish: Dull Chrome
